Awning blind for vertical windows VMZ - FAKRO

Awning blind for vertical windows - VMZ

VMZ awning blinds are designed for vertical joinery and can be fitted in windows and doors (terrace and balcony) made of PVC, aluminium or wood. The awning is available in electric version (VMZ Solar, VMZ Z-Wave, VMZ Electro) and in manual option (VMZ). Electric awning blinds can be integrated into an advanced technological solution of FAKRO smartHome system.

The markisolette can be controlled in one of three modes:

  • automatic (self-activating rolling up and unrolling dependent on the level of insolation) - VMZ Solar
  • semi-automatic (self-activating unrolling, rolling up via a remote control) - VMZ Z-Wave
  • operation via remote control supplied -  VMZ

Electric awning blinds are also available in the following versions:

  • VMZ – manual control. The blind is operated manually or by means of a control rod.
  • VMZ ZIP – manual control. The blind can act as an insect screen.
  • VMZ Z-Wave – powered by 15VDC mains supply and operated by means of a remote control or wall switch in the wireless Z-Wave system. It cooperates with FAKRO electric products equipped with the Z-Wave system (e.g. FTP-V Electro Z-Wave window or ARF Z-Wave blackout blind). In special cases, the awning can be controlled by a service button situated on it. A 15VDC power supply is required to power the awning.
  • VMZ Solar – powered by solar battery and operated by means of a remote control. In can be controlled using three modes:
    • automatic (self-activating rolling up and unrolling dependent on the level of insolation). In summer mode, the awning blind protects against excessive heat gain on a sunny day. In colder months, it is possible to manually switch the awning into winter mode. In this mode, in sunny weather, the awning rolls up automatically to allow the flow of warm sun rays, passively heating up the room. At low insolation level (from afternoon to morning or in cloudy weather) the awning is automatically rolled down to protect the room from heat loss.
    • semi-automatic (self-activating unrolling, rolling up via a remote control).
    • operated via supplied remote control. The Solar awning blind is powered by a 15VDC battery pack which is built into the cassette and recharged by the solar panel.
  • VMZ Electro 230  – powered by mains supply and operated via a wall switch (switch must be purchased separately). No power supply is required for the blind – the blind can be connected to 230V mains supply.
  • VMZ Electro 12 – powered by 15VDC mains supply and operated via a wall switch (switch must be purchased separately). In special cases, the awning can be controlled by a service button situated on it. A 15VDC power supply is required to power the awning.
  • VMZ Electro Solar – powered by the solar panel (battery pack included) and operated by means of a wall switch (switch must be purchased separately). In special cases, the awning can be controlled by a service button situated on it.*

* The Solar type awning blinds should be fitted in places with the solar panel positioned to direct sun exposure. It is recommended to install awnings on south, east and west-facing roofs. Installation in the north side may result in battery discharge and the inability to operate the blind. To ensure correct operation of the automatic mode, the solar panel must be exposed to direct sun sunlight throughout the active operation mode.







Gallery





  • VMZ


    • Ръчно управлениеmanual control by hand or via control rod
  • VMZ ZIP


    • Ръчно управлениеmanual control
      the blind can act as an insect screen
  • VMZ Z-Wave


    • Електрическо управление Z-waveZ-Wave system
    • Управление със ключ за стенаcontrolled by wall switch
    • Управление с дистанционноcontrolled by remote control
  • VMZ Solar


    • Соларно захранванеpowered by solar battery
    • Автоматично управлениеautomatic control
  • VMZ Electro 230


    • Управление със ключ за стенаcontrolled by wall switch
  • VMZ Electro 12


    • Управление със ключ за стенаcontrolled by wall switch
  • VMZ Electro Solar


    • Соларно захранванеpowered by solar battery
    • Управление със ключ за стенаcontrolled by wall switch

Relative open area



Relative open area

Price group I - fabric with 10% relative open area

Relative open area

Price group II - fabric with 1% relative open area

Relative open area

Price group III - fabric with 6% relative open area



Relative open area

Price group III - fabric with 4% relative open area





Colours of VMZ - Price group I



* In awning blinds with fabric 089, where the width exceeds 2100mm, the fabric consists of two parts and is joined together in the middle of the awning (horizontal welded connection).



Colours of VMZ - Price group II



* In awning blinds with fabric featuring 1% relative open area, where the width exceeds 2400mm, the fabric consists of two parts and is joined together in the middle of the awning (horizontal welded connection).



Colours of VMZ - Price group III - fabric with 6% relative open area



As a result of temperature changes or after a long period of non-use, the fabric used in VMZ awning blinds may slightly wave. Once unfolded, the fabric should return to its original state.



Colours of VMZ - Price group III - fabric with 4% relative open area

*In the case of 4% relative open area, products will come with the fabric consisting of two parts connected in the middle (horizontal welded connection).  In the case of samples 710 – 716, for dimensions close to the maximum size, the fabric can consist of three parts.

Instructions and catalogues
